VHF End Fed Dipole
$593.29 inc GST
The Hi-Tec Aerials PRO-EFDV is a neat, rugged end-fed half-wave VHF antenna for 138–170 MHz. It suits paging, telemetry and base stations where a tidy installation matters. It arrives factory assembled and tuned, so there’s nothing to assemble or adjust.
- Tuned to your spot frequency within 138–170 MHz (state it on your order)
- 0 dBd, 5 MHz bandwidth, 25 W (intermittent use)
- Sealed in a rugged fibreglass radome on an anodised aluminium mounting tube
- Supplied with a 1 m RG58 tail, unterminated, no clamp
- Customisable: cable length and mounting
Neat, pre-tuned and easy to install
The PRO-EFDV is an end-fed vertical half-wave dipole for 138–170 MHz. It is ideal for paging and similar systems where a clean, rugged installation is needed. Each antenna is factory assembled and tuned to your frequency, then sealed in a rugged fibreglass radome. The radome is fitted to a short anodised aluminium tube for mounting, and the RG58 coax tail exits through the end of the tube, so there are no exposed joints.
Ordering
Each PRO-EFDV is tuned to a spot frequency. Please include your operating frequency in the order notes or contact us. As standard it is supplied with a 1 m RG58 tail, unterminated, and no clamp. Longer tails are available, and the Universal Clamp can be added for mounting to a vertical or horizontal support. To fit a connector, see our Telegärtner connectors.
For higher power or harsher sites, see our VHF shrouded dipole, professional folded dipoles and VHF collinears. Signals NZ and Hi-Tec Aerials supply, install and service radio systems across New Zealand, and fit lightning protection.
Specifications
| Model | PRO-EFDV |
| Frequency range | 138–170 MHz (tuned to spot frequency) |
| Bandwidth | 5 MHz |
| Gain | 0 dBd |
| Impedance | 50 Ω |
| Return loss / VSWR | < −14 dB / 1.5:1 |
| Maximum power | 25 W (intermittent use) |
| Cable (standard) | RG58, 1 m, unterminated |
| Overall height | 1.55 m |
| Projected area | 0.06 m² |
| Weight | 1.3 kg |
| Mounting tube diameter | 38 mm |
Additional information
| Weight | 1.3 kg |
|---|---|
| Brand | Hi-Tec |
| Band | VHF |
| Frequency | 138–170 MHz, tuned to spot frequency |
| Standard Build | RG58 1 m tail, unterminated, no clamp |
| Customisable | Cable length, mounting |
