Icom HM-195GB CommandMic
$610.65 inc GST
The Icom HM-195GB is an extra CommandMic for the Icom IC-M423G and IC-M510 EVO fixed VHF radios and the IC-M410BB and IC-M510BB black box VHF radios. Add another station for full radio control and intercom from the cockpit, flybridge or tower. IPX7 waterproof, black, with a 6.1 m cable included.
The HM-195GB CommandMic gives you full control of your Icom IC-M423G, IC-M510 EVO or black box VHF from a second or third position on board, including channel selection, DSC calls and, on the IC-M510BB, AIS screens. Each CommandMic can also be used as an intercom, with one-to-all or one-to-one calls between stations.
It's the same IPX7 waterproof CommandMic supplied with the IC-M410BB and IC-M510BB, so it can be mounted in open areas such as a tower or flybridge where it may be exposed to rain and spray.
Key features
- Extra radio station: full VHF and DSC operation from another position on board.
- Intercom: one-to-all or one-to-one communication between CommandMic stations.
- Compatible with the Icom IC-M423G (2 stations total), Icom IC-M510 EVO, Icom IC-M410BB (up to 2 stations total) and IC-M510BB (up to 3 stations total).
- IPX7 waterproof for exposed helm positions.
- On the black box radios, mount up to 18.3 m from the RF unit with two optional OPC-1541 extension cables.
Specifications
| Model | HM-195GB (black) |
| Compatible radios | Icom IC-M423G, IC-M510 EVO, IC-M410BB, IC-M510BB |
| Ingress protection | IPX7 |
| Audio output | More than 2 W (4 Ω) |
| Dimensions | 67.5 × 144.5 × 37 mm |
| Weight | 400 g |
Download IC-M410BB / IC-M510BB Brochure (PDF)
What's in the box
- HM-195GB CommandMic
- OPC-1540 6.1 m cable
- Microphone hanger
- Mounting base for connector
Contact us for installation advice or to order OPC-1541 extension cables.
Additional information
| Weight | 0.4 kg |
|---|---|
| Dimensions | 3.7 × 6.75 × 14.45 cm |
| Brand | Icom |
| Ingress Protection | IPX7 |
| Compatible With | IC-M423G, IC-M510 EVO, IC-M410BB, IC-M510BB |
| Colour | Black |
